Xiegu XPA125B HF Linear Amplifier with ATU 100W, 0.5–54MHz

Xiegu XPA125B HF Linear Amplifier with Built-in ATU

The Xiegu XPA125B is a compact, all-solid-state 100W HF linear amplifier with a built-in automatic antenna tuner (ATU), designed to pair seamlessly with Xiegu QRP transceivers including the X5105, X108G, G90 and G1M. Covering 0.5 to 54MHz, it transforms a low-power portable rig into a capable 100W+ station with minimal setup. The CNC-machined chassis includes comprehensive input and output protection, making it a reliable choice for both home and field use.

Key Features

• 100W output from as little as 5W input — ideal for Xiegu QRP rigs
• Built-in ATU with tuning range of 14–500Ω
• All-solid-state design with CNC-machined enclosure
• Built-in input and output protection circuits
• Covers HF through 6m (0.5–54MHz)
• Compatible with Xiegu X5105, X108G, G90 & G1M transceivers
• Compact and suitable for portable or base station use

Technical Specifications

• Working Frequency: 0.5–54MHz
• Input Power: ≤5W
• Max Output Power: ≥110W (1.8–30MHz) / ≥90W (50–54MHz)
• ATU Tuning Range: 14–500Ω
• Working Voltage: 12–14.5V DC
• Standby Current: 260mA
• Max TX Current: 30A
